Firstly, if you are replacing one of the units - place the unit that you are replacing away to prevent any confusion.
if you are replacing the Parent Unit, you will need to remove the battery from the original Parent Unit:
- Switch ON the Nursery / Camera Unit & Parent Unit
- Press the Parent Unit screen to access the menu
- Press the menu icon
- Press the Setting function
- Press the Pairing icon
- Press Nursery / Camera Unit 1
-
The linking icon will appear on the screen
-
Turn ON the Nursery / Camera Unit and press and hold its “pause/pairing” button until the power LED starts flashing while pairing
-
If the connection has been made, the Green Successful Pairing Icon will appear on the screen and the menu will show the OK Paired Icon
-
Otherwise, the Red Failed Pairing Icon will appear on the screen. You will need to try again
Here is a video that shows you how to connect the Parent Unit with the Nursery / Camera Unit:
________________________________________
If you have replaced the Parent Unit, you will also need to connect the Sensor Pad to your replacement Parent Unit:
-
Remove the battery of the Sensor Pad
-
Press the Parent Unit screen to access the menu
- Press the menu icon
-
Press the Setting icon
- Press the Pairing icon
Press the Sensor Pad 1
The linking icon will appear on the screen until Successful Pairing Icon appears on the screen.
-
Insert the battery into the Sensor Pad. It will automatically activate the Sensor Pad.
-
If the connection has been made, the Green Successful Pairing Icon will appear on the screen and the menu will show the OK Paired Icon
-
Otherwise, the Red Failed Pairing Icon will appear on the screen. You will need to try again
Here is a video that shows you how to connect the Parent Unit with the Sensor Pad:
